Under ZJL type liquid slurry pump Details

First, under 40ZJL-35A liquid slurry pump | vertical submerged pumps | vertical slurry pumps under security workers ensure quality liquid slurry pump Product Overview

ZJL slurry pump is a single stage, single suction, centrifugal, vertical slurry pumps, is my company's main product is mainly used in electric power, metallurgy, coal, building materials, chemical and other industries handling corrosive solids-containing a new generation of energy-efficient slurry of single-stage, single-suction centrifugal slurry pump. They are mainly applied to the concentrator processing ore and tailings, in addition to thermal power plant ash, coal preparation plant slime and transport heavy medium preparation, coastal sand excavation job conveying mortar and the like. Maximum weight concentration of the slurry can be handled as follows: 45% mortar, pulp 60%.

Second, under 40ZJL-35A liquid slurry pump | vertical submerged pumps | vertical slurry pumps under security workers ensure quality liquid slurry pump Product Features

ZJL is single stage, single suction, vertical centrifugal slurry pump, which pumps the use of advanced solid-liquid two-phase flow theory the international level, according to the principles of design minimal losses. Its flow components geometry consistent with medium flow, reducing the eddy current and impact other local and along the water loss, thus reducing the flow parts wear and improved hydraulic efficiency, reduce operating noise and vibration; this series of pumps flow components using high-hard cast iron alloy, the material having a high abrasion resistance, corrosion resistance, impact resistance, making it increasing life expectancy.

Third, under 40ZJL-35A liquid slurry pump | vertical submerged pumps | vertical slurry pumps security workers under liquid slurry pump ensuring quality working conditions

Speed: Direct motor drive 2900/1480/980/730/590 / r / min

Union between pulley transmission line with customer requirements

Medium temperature: general ≤80 ℃

Special up to 110 ℃

Solid-liquid mixture weight concentration: Mortar concentration ≤45%

Pulp density ≤60%

Fourth, the main purpose under liquid slurry pump

ZJL slurry pump is generally immersed in tanks or pit work, without any shaft seal and seal water. Plus the long axis of the series sump pump, applicable to the deeper level of working conditions. This type of pump used in mining, metallurgy, electricity, coal, chemicals, building materials industries, transportation abrasive and corrosive slurry containing solid particles, the solid-liquid mixture maximum weight concentration: 45% mortar, pulp 60%.

Fifth, under 40ZJL-35A liquid slurry pump | vertical submerged pumps | vertical slurry pumps slurry pump type and quality of security workers security significance
